Soviet Transformer |
---|
About This Item
Every Stalin-era and Khrushchev-era train set produced by the Soviet Union in the
1950's and 1960's included a 75-watt transformer -- also called a "speed regulator" or "power
supply." The design of this piece was pilfered from
Jefferson Electric (who also made transformers for American Flyer) and it represents yet
another example of stealing shamelessly.
The faceplate and rear data plate are painted black
with raised letters in brass. A red lens covers a short-circuit indicator bulb and a black
button is used to reset the unit to clear the short circuit. There are three binding posts: one
for fixed voltage, one for variable voltage and one for ground. The output is 5 to 13 volts.
The line cord is black and the electrical plug is a European-style 2-prong type.
The cases were painted various colors, including olive green, red, "brownish red" and maroon.
The transformer is round, measures 5 ½ inches across and 4 ¾ inches high and
weighs 5 pounds.
The transformers included in the earlier sets were made to accommodate the standard
Soviet household current of 127 volts. However, during the 1950's and 1960's, the Soviets
converted to 220 volts and the later sets included a transformer designed for 220-volt input.
A number of sets have been found with a
voltage reducer device that may have
been supplied as original equipment with the set -- either because the 220-volt transformer had
not been produced yet or because the Soviets needed to exhaust existing inventory of the
127-volt transformers. More likely, the "step-down" apparatus was purchased separately by
owners of earlier sets with 127-volt transformers who were living in households that had been
converted to 220 volts.
The 127-volt transformers were first made in 1951. It is not known when the 220-volt transformer
replaced the 127-volt transformer or when the 220-volt transformer was last made.
Soviet Transformer photos |
---|
ABOVE: 127-volt Transformer and RARE Original Box |
ABOVE: Early 127-volt transformer: data plate has "MEP" and "CCCP" |
ABOVE: Later 127-volt transformer: data plate has "MOCHX" and "PCFCP" |
ABOVE: A 220-volt transformer: data plate has "MCHX" and "PCFCP" |
ABOVE: Transformers painted three different colors |
Variations
Some (or most?) of the Stalin-era sets came with a 127-volt transformer.
However it is unclear whether all Stalin-era sets came with a 127-volt transformer or if some
came with the later 220-volt transformer. Some (or most?) of the Khrushchev-era sets came with
a 220-volt transformer. However it is unclear whether all Khrushchev-era sets came with a
220-volt transformer or if some came with a 127-volt transformer.
The basic design of the Soviet transformer remained unchanged throughout its life. The
shape and top plate of a 127-volt transformer look the same as those of a 220-volt transformer.
The differences are in the plug -- which will have either "127v" or "220v" on it -- and the
information shown on the data plate. Most of the information on the data plates are the same.
However where the early 127-volt transformer has these abbreviations: "127v" -- "M E P"
(Ministry of Electro-technical Industries) and "C C C P" (Union of Soviet Socialist Republics),
the later 127-volt transformer has these abbreviations: "127v" -- "M O C H X" (Moscow City
Council of National Economy) and "P C F C P" (Russian Soviet Federal Socialist Republic) on it.
(This item may represent a transition piece -- possibly representing the fact that a different
government organization had responsibility for overseeing the production of these items.)
The 220-volt transformer's data plate has "220v" and also the same "P C F C P" (Russian
Soviet Federal Socialist Republic) on it but curiously the abbreviation for the Moscow City
Council of National Economy was shortened to "M C H X" -- the reason is unclear.
Other than input voltage, the only other variations will be
due to the color of the bases. A serial number is stamped on the data plate and may help in
determining year of production. The original box -- which is very rare -- is made of soft brown
cardboard which is held together by staples. The box opens from the top and is extremely flimsy,
especially given the heavy item it was intended to protect! Naturally, very few have survived.
The box is square and measures 6 3/4 inches wide by 6
3/4 inches deep by 5 1/4 inches high.
Neither the box nor the lid have any printing or identification marks.
