About This Accessory
A metal gate crossing of stamped-steel construction was included in every
Stalin-era and Khrushchev-era train set produced by the Soviet Union in the 1950's and 1960's.
The design of this piece was pilfered from Märklin and it represents yet another example of
stealing shamelessly. The accessory has two 4-inch gates with supports, a 12-inch section of
straight track and four sections of decorative fencing with fence posts on both ends of each
3-inch section.
The gates are lowered mechanically when the train passes over an activator rail
(lever mechanism) built into the track that is in the center of the base. (The gate crossing is
part of the
track sequence and
either has the number "3" stamped on the underside of the base or has a metal tag stamped with
the number "3" on it and attached to the underside of the base.) If properly connected via the
wiring harness furnished with each set, this electro-mechanical accessory will perform
another function -- sounding the horn inside the
passenger station!
The gate arms are
red and white striped and the counterweights are painted black. However the bases, gate
supports, fencing and fence posts were painted in many different colors. The stand-alone fence
boards resemble a picket fence and the posts have rectangular caps.
An examination of the
1951 instruction manual has revealed an illustration of an
older-style gate crossing that is
much fancier than the one described above. It is unknown as to when manufacturing of the
old-style gate crossing ceased and when the newer one was introduced. However, it is believed
that very few of the older style were made and therefore the newer one was available in
1951 or very close to that year. While various other Khrushchev-era items were made as late as
1969, it is likely that production of the gate crossing stopped much earlier. Further adding to
the mystery is the fact that the operating instruction manuals contained illustrations of the
early-style gate crossing through at least March 1957 -- long after it was out of production!
The newer-style gate crossing appears in the March 1958 manual and in all subsequent manuals.
Photos of five different Soviet Gate Crossings (newer style) |
---|
ABOVE: Version with metallic green base and red fencing. |
ABOVE: Version with copper-brown base and green fencing. |
ABOVE: Version with olive-green base and green fencing. |
ABOVE: Version with tan base and green fencing. |
ABOVE: Version with gray base and pink fencing. |
Variations
There are apparently no differences in the newer-style gate crossing that was included with the Stalin-era sets versus the Khrushchev-era sets. However many variations have surfaced resulting from the many colors used to paint the bases, gate supports, fencing and fence posts. This accessory is not easy to find in collector-quality condition.
This page is an information document only; nothing on this web page is being offered for sale. This page and all of the other pages from Our Soviet Archives were developed to assist you in understanding the components of the train sets produced in the Soviet Union during the 1950's and 1960's. These sets are known today as "Stalin-era" sets and "Khrushchev-era" sets. We have used pictures from our old files and personal collection to construct this area of our website. If you are interested in buying something, please view our inventory listings to see what we currently have for sale.
This web page was last updated on September 11, 2005. If you have suggestions for improving this page or if you see any errors, please contact us.
